XCMG RP355 Mini Tracked Asphalt Paver

Overview

The XCMG RP355 is the flagship of XCMG’s 5-series mini tracked pavers. XCMG’s expert review describes it as a small, highly maneuverable machine with full hydraulic drive and an intelligent electronic control system, used mainly for milling-slot and gully backfill, urban non-motorized lane construction, island and tourist-road building, landscaping, residential roads and stadium surfaces, plus indoor and height-restricted work sites.

With a transport width of just 1.45 m and a height under 2 m, it fits low-clearance and narrow-access conditions that full-size pavers cannot reach.

Core Specifications (China Configuration)

The following values are taken from the current XCMG China product page.

Parameter	Value
Basic paving width	1.2–3.2 m
Max. paving width	3.2 m
Max. paving thickness	200 mm
Theoretical productivity	300 t/h
Hopper capacity	5.8 t
Engine power	55.8 kW
Screed heating	Electric
Operating weight	8–8.3 t
Transport dimensions (L×W×H)	5,360 × 1,450 × 1,935 mm

The China intro text specifies a Yuchai water-cooled turbocharged electronic-control diesel engine; the engine model code is not published.

Export Configuration (Stage Ⅲ)

XCMG’s global and Australian official pages list a Cummins-powered export configuration with a more complete specification. These values are shown separately rather than merged with the China data.

Parameter	Value
Basic paving width	1,200–2,200 mm
Max. paving width (bolt-on options)	2,500–3,500 mm
Max. paving thickness	200 mm
Max. paving speed	25 m/min
Max. drive speed	3.2 km/h
Max. theoretical productivity	300 t/h
Max. gradeability	20%
Engine model	Cummins QSF2.8
Emission	EU Stage Ⅲ
Rated power	53 kW @ 2,200 r/min
Crawler grounding length / track width	1,673 / 180 mm
Auger max. speed / diameter	70 r/min / 300 mm
Battery voltage	24 V
Tractor / operating / total weight	6.8 / 7.2 / 7.5 t
Noise (operator ear / emitted)	80 / 103 dB(A)
Transport dimensions (L×W×H)	4,650 × 1,450 × 1,935 mm
Screed	E1122T hydraulic extending, electric heating, single tamper
Leveling / control	MOBA leveling and material-level instruments, intelligent control, wireless remote

XCMG’s Australian datasheet also lists a main-dimension table with an overall length of 4,910 mm, while the global page summary lists 4,650 mm for transport; both are official figures and may reflect different measurement points.

Version Differences

Item	China	Export (Stage Ⅲ)
Engine	Yuchai electronic-control diesel, 55.8 kW	Cummins QSF2.8, 53 kW
Basic paving width	1.2–3.2 m	1.2–2.2 m (up to 3.5 m with options)
Operating weight	8–8.3 t	7.5 t total
Transport length	5,360 mm	4,650 mm

Key Features

XCMG groups the RP355’s selling points as follows:

• Compact and agile: 1.45 m machine width and sub-2 m height for low, narrow and indoor work sites.
• Full hydraulic independent drive: load-sensing control delivers efficient, fuel-saving power output.
• Yuchai electronic-control diesel: water-cooled turbocharged engine with ample power reserve and good economy.
• Integrated intelligent control: consolidated wiring harness and a multi-function display panel for closer human-machine interaction.
• Export-package extras (per official datasheet): ECO engine mode, auto-adjusting cooling fan, wireless remote control, one-key automatic mode for auger/conveyor/tamper, two-time folding hopper with single-wing control, and an anti-block high-torque feeding motor for high-viscosity asphalt.

Applications

Milling-slot and gully backfill, urban non-motorized (bicycle) lanes, island and tourist-attraction roads, landscaping, residential community roads, stadium surfaces, and paving inside workshops, garages and other height-restricted sites.

Data Source

XCMG official China product page: RP355 (review text via the official review page), fetched on 2026-10-07. Export figures follow the official global page RP355 and XCMG Australia’s official RP355 datasheet PDF (2025-03-27). Third-party data on machmall (XCMG’s official e-commerce store) matches the export configuration.

Specifications and configurations may vary depending on options, batch and regional regulations. XCMG reserves the right to make changes without prior notice; final figures must be confirmed after order placement.
