XCMG XE210WLL Long Reach Excavator
A 20.7-ton long reach wheeled excavator with a Cummins QSB7 135 kW engine, 0.5 m³ bucket, 12.6 m maximum reach and 31 km/h travel speed.
Operating Weight
20,700 kg
Bucket Capacity
0.5 m³
Engine Power
135 kW
Engine Model
Cummins QSB7
Verified Data
Complete Specifications
Source: official product data
| Specification | Value |
|---|---|
| Operating Weight | 20,700 kg |
| Bucket Capacity | 0.5 m³ |
| Engine Power | 135 kW |
| Engine Model | Cummins QSB7 |
| Max. Digging Radius | 12.6 m |
| Bucket Digging Force | 144 kN |
| Arm Digging Force | 100 kN |
| Travel Speed (H/L) | 31 / 9.5 / 3 km/h |
| Swing Speed | 10.5 r/min |
Overview
The XCMG XE210WLL is a 20.7-ton long reach wheeled excavator built for work that needs more reach and mobility than a standard earthmoving excavator. XCMG positions it for municipal construction, port operations, river dredging, lake cleaning, reservoir maintenance and slope work.
The long boom configuration, extended chassis and wheeled undercarriage make it especially useful where the machine must cover a wide working area or move between work points without transport.
Core Specifications
| Parameter | Value |
|---|---|
| Operating weight | 20,700 kg |
| Rated engine power | 135 kW |
| Engine model | Cummins QSB7 |
| Bucket capacity | 0.5 m³ |
| Maximum working radius | 12.6 m |
| Travel speed | 31 / 9.5 / 3 km/h |
| Swing speed | 10.5 r/min |
| Bucket digging force | 144 kN |
| Arm digging force | 100 kN |
Engine
| Parameter | Value |
|---|---|
| Engine model | Cummins QSB7 |
| Rated power | 135 kW |
| Maximum torque / speed | 740 N·m @ 1,200 rpm |
| Displacement | 6.7 L |
| Emission standard | National Stage III |
Working Range and Undercarriage
| Parameter | Value |
|---|---|
| Maximum working radius | 12.6 m |
| Travel speed | 31 / 9.5 / 3 km/h |
| Swing speed | 10.5 r/min |
Key Features
- Long-reach boom: the official page lists a 12.6 m maximum working radius for dredging, slope work and wide-area cleanup.
- Stability package: XCMG states that the standard front dozer blade, rear outriggers and extended chassis improve working stability.
- Kawasaki hydraulics: the China page states that the main pump, large-diameter main valve and high-torque swing motor are Kawasaki units.
- Travel and axle system: XCMG states that the German-imported Linde travel motor and ZF axle/ gearbox provide good gradeability and comfortable travel.
- Wide application range: the global page highlights municipal construction, port work, river dredging, lake cleaning, reservoir maintenance and slope operations.
Applications
Municipal construction, port operations, river dredging, lake cleaning, reservoir maintenance, slope construction, agricultural land improvement, wetland work and soil stripping after water pumping.
Data Source
XCMG official China product page: XE210WLL, fetched on 2026-10-04. Additional specifications follow the XCMG global product page: XE210WLL.
Specifications follow the XCMG official pages and may vary by batch and configuration. Final configuration and figures must be confirmed after order placement.
Data Source
Specifications are taken from XCMG's published product data. Figures can vary by configuration, market and emission stage — we confirm the exact figures for your machine in the quotation, and we can send the original datasheet on request.
